      供应bliley BQCSA/BQCT1/BQCSQ等型号晶体

      发布时间：2024-01-22 15:46:47     浏览：1719

      PackageTypeFreq RangeTemp RangeStabilityDatasheet
      BQCSA5.0mm x 7.0mmSMD5.5 to 125MHz-20°C to +70°C,
      -40°C to +85°C      		±15ppm,
      ±20ppm,
      ±50ppm
      BQCSB6.0mm x 3.5mmSMD8 to 125MHz-20°C to +70°C,
      -40°C to +85°C      		±15ppm,
      ±20ppm,
      ±50ppm
      BQCSC5.0mm x 3.2mmSMD10 to 150MHz-20°C to +70°C,
      -40°C to +85°C      		±15ppm,
      ±20ppm,
      ±50ppm
      BQCSD4.0mm x 2.5mmSMD12 to 54MHz-20°C to +70°C,
      -40°C to +85°C      		±15ppm,
      ±20ppm,
      ±25ppm
      BQCSF2.5mm x 2.0mmSMD12 to 60MHz-20°C to +70°C,
      -40°C to +85°C      		±15ppm,
      ±20ppm,
      ±50ppm
      BQCSG2.0mm x 1.6mmSMD16 to 60MHz-20°C to +70°C,
      -40°C to +85°C      		±15ppm,
      ±20ppm,
      ±50ppm
      BQCSM3.2mm x 2.5mmSMD10 to 150MHz-20°C to +70°C,
      -40°C to +85°C      		±15ppm,
      ±20ppm,
      ±50ppm
      BQCSN1.6mm x 1.2mmSMD24 to 54MHz-20°C to +70°C,
      -40°C to +85°C      		±15ppm,
      ±20ppm,
      ±50ppm
      BQCSP6.0mm x 3.5mmSMD8 to 125MHz-20°C to +70°C,
      -40°C to +85°C      		±15ppm,
      ±20ppm,
      ±50ppm
      BQCSQ1.6mm x 1.0mmSMD32.768kHz-20°C to +70°C,
      -40°C to +85°C      		-0.04ppm/°C^2
      BQCST3.2mm x 1.5mmSMD32.768kHz-20°C to +70°C,
      -40°C to +85°C      		-0.04ppm/°C^2
      BQCSV5.0mm x 3.2mmSMD8 to 80MHz-20°C to +70°C,
      -40°C to +85°C      		±15ppm,
      ±20ppm,
      ±30ppm,
      ±50ppm
      BQCSW8mm x 8mmSMD10 to 150MHz0°C to +70°CB
      -20°C to +70°C
      -40°C to +85°C      		±25ppm
      ±50ppm
      ±100ppm
      BQCT1HC-37/U PackageSMD2 to 60MHz-20°C to +70°C,
      -40°C to +85°C
      10°C to +60°C      		±10ppm
      ±20ppm
      ±50ppm
      BQCT3UM5Thru-Hole10 to 100MHz-10°C to +60°C,
      -20°C to +70°C,
      -40°C to +85°C      		±10ppm,
      ±20ppm,
      ±50ppm
      BQCTHHC-49/UThru-Hole1.536 to 130MHz-10°C to +60°C,
      -20°C to +70°C,
      -40°C to +85°C      		±15ppm,
      ±20ppm,
      ±50ppm
      BQCTRHC-51/UThru-Hole500kHz to 350MHz-20°C to +70°C,
      -40°C to +85°C      		±15ppm,
      ±20ppm,
      ±50ppm
      BQCTUUM1Thru-Hole10 to 100MHz-10°C to +60°C,
      -20°C to +70°C,
      -40°C to +85°C      		±10ppm,
      ±20ppm,
      ±50ppm

      更多Bliley 相关产品信息可咨询新葡萄AMG创展。
