WKP102MCPEJ0KR单层陶瓷电容器Vishay
发布时间：2024-04-30 09:23:10 浏览：685
WKP102MCPEJ0KR是Vishay生产的单层陶瓷电容器，适用于需要控制功率输入并提供更低成本组件的电路设计。该电容器能够承受760VAC|500VAC的电压，并在最高工作温度为125°C的环境下正常工作。此款高频电容器采用径向端接方式，深度为6mm(最大)，公差为20%，电容值为0.001uF。其引线直径为0.8mm，间距为12.5mm。
具体特征包括：
- 电容器由两面镀银的陶瓷盘组成
- 连接引线由直径为0.6毫米或0.8毫米的镀锡铜制成
- 电容器可提供直线或扭结引线，引线间距为10.0mm或12.5mm
- 涂层采用符合UL 94 V-0标准的蓝色阻燃环氧树脂
电容范围：33pf ~ 4.7 nF
电容公差：±10%，±20%
额定电压
?X1: 760 VAC, 50 Hz (IEC 60384-14)
760 VAC, 50 Hz / 60 Hz (US/UL/CSA 60384-14)
?Y1: 500 VAC, 50 Hz (IEC 60384-14)
500vac, 50hz / 60hz (US/UL/CSA 60384-14)
测试电压
?4000vac, 50hz, 2s组件测试(100%)
?4000 VAC, 50 Hz, 60 s随机抽样测试(破坏性)
?4000vac, 50hz, 60s耐压涂层(破坏性)
500vdc时的绝缘电阻：≥10000 MΩ(60秒)
耗散因子
第一类:最大0.5% (1khz)
第二类:最大2.5% (1khz)
此外，WKP102MCPEJ0KR陶瓷电容器符合IEC 60384-14标准，具有高可靠性，并提供多种不同的引线样式。
该电容器的应用包括符合IEC 60384-14标准的X1、Y1类型应用，以及线对线滤波(X类)和线对地滤波(Y类)。
