T30D1 Ku频段混合隔离器环形器
发布于：2024-09-20 15:53:38
品牌名称：Sonoma Scientific
重要参数：
频率：13.75-31.5GHz
功率：<5W
驻波比：1.25
隔离度：20
| Model # | Start Freq | Stop Freq | Isolation | Insertion Loss | VSWR | Operating Temp (°C) | Configuration/Style | Pwr Fwd | Size |
| T30D1 | 30.75 GHz | 31.5 GHz | 20 | 0.45 | 1.25 | 45 | PIN I/P TO K | 4W | .98 X .50 X .38 |
| T28A1 | 28 GHz | 30.5 GHz | 20 | 1 | 1.25 | 0+50 | PIN I/P TO K FEMALE | .1W | .64 X .64 X .50 |
| T28A1 | 28 GHz | 30.5 GHz | 20 | 1 | 1.25 | 0+50 | PIN I/P TO K FEMALE | .1W | .64 X .64 X .50 |
| T27D1 | 27.75 GHz | 28.5 GHz | 20 | 0.45 | 1.25 | 45 | PIN I/P TO K FEMALE | 4W | .98 X .50 X .38 |
| T27D1 | 27.75 GHz | 28.5 GHz | 20 | 0.45 | 1.25 | 45 | PIN I/P TO K FEMALE | 4W | .98 X .50 X .38 |
| T18J1 | 18 GHz | 20.7 GHz | 20 | 1 | 1.25 | 0+50 | PIN I/P TO K FEMALE | .1W | .64 X .64 X .50 |
| T13J1 | 13.75 GHz | 14.5 GHz | 20 | 0.5 | 1.25 | 45 | PINS/TABS | 5W | .50 X .60 X .50 |
